Architectural Plans

Site, Sweet Site

We have four basic unit types, color coded on the site plan above. Floor plan sketches (as of early Nov'97) are linked in this table (10-15Kbytes each). Checkout our Common House plans (and its basement, too).

UNIT
TYPE
DESCRIPTION Floor Plans
On-Line

A 1 bedroom / 1 bath: 743 sq.feet.
Additional basement: 685 sq.feet.
main floor
basement

basement (walkout)

A' 1 bedroom / 1 bath: 678 sq.feet.
Additional loft with bed and bath: 371 sq.feet.
main floor
loft space

B 2 bedroom / 1 bath on one floor: 978 sq.feet.
Additional basement: 978 sq.feet.
first floor
basement

basement (walkout)

C 2 bedroom / 1-1/2 bath on two floors: 1100 sq.feet total.
Additional basement of 520 sq.feet.
first floor
second floor

basement

basement (walkout)

D 4 bedroom / 3 bath on two floors: 1544 sq.feet total.
Additional basement of 776 sq.feet.
first floor
second floor

basement

basement (walkout)

MTA Our local architect.
Back to our Home Page
